Pioneer of domestic suspension for off-road use

We offer a package that includes all the parts needed to change the suspension lift, such as coils or leaves, shock absorbers, and boots.

Please choose according to the target model and the amount of lift.

Use the damping force adjustment mechanism.

From on-road to rugged off-road, there are a wide variety of environments in which 4WDs can operate.
By adjusting the damping force of the shock absorber to the optimum value according to the driving environment, the true potential of the vehicle can be brought out even more.
Basic knowledge about damping force adjustment and tips for adjusting to the optimum value are summarized in "Recommendations for Damping Force Adjustment". Please take a look.

New shock absorber mechanism for both ride comfort and handling stability

Frequency-sensitive shock absorber "HARMO-FLEX" is adopted (*on some models)

"HARMO-FLEX" is a frequency-sensitive shock absorber, a new shock absorber mechanism developed by KYB Corporation to achieve both ride comfort and driving stability, and mass production of which began in 2009.

With conventional shock absorbers, the damping force is almost constant even if the vibration frequency changes as long as the speed remains the same.

On the other hand, "HARMO-FLEX" reduces the vibration of the vehicle body by setting the damping force lower than that of conventional shock absorbers for vibration frequencies of 3Hz or higher, which is the frequency at which humans perceive ride comfort to be good or bad.

Conversely, the damping force is set higher than that of conventional shock absorbers when the resonance frequency on the spring is below about 1.5Hz. This prevents deterioration of handling stability due to insufficient rise of damping force.

In this way, by automatically changing the damping force according to the vibration frequency of the road surface and vehicle body, the vehicle's handling stability can be enhanced while ride comfort can be greatly improved.

*Depending on the model of car, changing the ride height by installing our ride height adjustment parts may also require changing the settings of the cameras, sensors, and radars installed in the car. If not properly adjusted, the various safety equipment (such as collision avoidance and other driving support systems) in the car may not operate properly. Also, please note that there is a possibility that the vehicle will not meet the front side visibility standard (Article 44, Paragraph 5 of the safety standard).

*We are not responsible for any accidents caused by the malfunction of the camera, sensor, radar, or driver assistance system due to the installation of our parts. Please understand beforehand.

4x4 Engineering Services History of Suspension Development

"I want to make a domestic suspension specifically for off-road use."

In the 1970's, the only 4x4 suspension products available in Japan were commercial vehicles that were not very comfortable to drive. The only way to get a full-fledged 4x4 suspension that could be used for racing was to order products from European and American manufacturers. We had a strong desire to create a domestic suspension for off-road use.

In the city of Kani, Gifu Prefecture, where 4x4 Engineering Service was based (now relocated to Higashi-ku, Nagoya City, Aichi Prefecture), there is now a plant and development base of Kayaba Industries (now KYB Corporation), one of the world's leading shock absorber manufacturers. With this local connection, we were able to develop a new suspension system specifically for 4x4 vehicles.

In 1980, we launched the Country Challenge, the first high-pressure mono-tube shock absorber specifically designed for 4x4. Since then, we have been expanding our product lineup by gradually responding to the requests of our customers to accommodate their vehicle models.

"The off-road field is the place where new products are born."

In 1981, we launched the "Country Suspension", a plate spring made in Japan exclusively for 4WD. Designed exclusively for the Toyota Land Cruiser 40 series, Mitsubishi Jeep, etc., it was developed to improve ride comfort and further enhance off-road performance. Later, the company released a plate spring painted in "Country Suspension Blue" from the Land Cruiser 70 series spring. Since then, all springs developed by 4x4 Engineering Service, both plate springs and coil springs, have been painted with this "COUNTRY SUSPENSION BLUE" color.

In 1984, a twin-tube low-pressure shock absorber was introduced in response to the problem that the shock absorber would heat up under severe conditions such as off-road racing, and would not be able to exert the desired damping force. By quickly adopting the latest technology from Kayaba Industry, we were able to achieve a high-performance suspension that overwhelmed our rivals. Even today, we continue to gather information on new technologies and conduct tests to improve ride comfort and driving performance, aiming for further performance and quality improvements.

The "blue spring," a feature of the COUNTRY SUSPENSION, dominated domestic off-road racing at the time, and some teams even went to the trouble of repainting it a different color and using it with consideration for their sponsors.

In addition to the goal of winning races, we continue to develop new products based on the idea that the off-road field is a testing ground for new products that have yet to be developed.

Suspension Kit Itemized Statement (pdf)

LAND CRUISER 60

HJ61

LAND CRUISER 70

HZJ73 PZJ70 hZJ70(hood roof) HZJ77 HZJ76 GRJ76 GRJ79 GRJ79 for Heavy Load GDJ76

LAND CRUISER 80

LAND CRUISER 100

LAND CRUISER PRADO

150 90

Others

HILUX 125 FJ CRUISER HILUX SURF

LAND CRUISER 60

Item Number

71609-11

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

277,600yen (305,360yen)

Lift

70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / Short x 4 pcs.
Item Number

71609-12

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

287,600yen (316,360yen)

Lift

Front 70mm
Rear 90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / 2 short, 2 long
Item Number

71609-13

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

297,600yen (327,360yen)

Lift

90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / 4 long
Item Number

71609-51

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

293,600yen (322,960yen)

Lift

70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / 4 short
Item Number

71609-52

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

303,600yen (333,960yen)

Lift

Front 70mm
Rear 90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / 2 short, 2 long
Item Number

71609-53

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

313,600yen (344,960yen)

Lift

90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

---

Stabilizer stay set

Yes

notes

Alshackle / 4 long
Item Number

71609-51S

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

309,100yen (340,010yen)

Lift

70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

Yes

Stabilizer stay set

Yes

notes

Alshackle / 4 short
Item Number

71609-52S

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

319,100yen (351,010yen)

Lift

Front 70mm
Rear 90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

Yes

Stabilizer stay set

Yes

notes

Alshackle / 2 short, 2 long
Item Number

71609-53S

Compatibility

HJ61V / Aug.1987-Sept.1989

List price(Tax included)

329,100yen (362,010yen)

Lift

90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping force adjustment)

Absorber(R)

Yes (8-level damping force adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Steering damper

Yes

Stabilizer stay set

Yes

notes

Alshackle / 4 long

LAND CRUISER 70(HZJ73)

Item Number

71730-11

Compatibility

HZJ73 / Jan.1990-Aug.1999

List price(Tax included)

255,000yen (280,500yen)

Lift

60mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / 4 short
Item Number

71730-12

Compatibility

HZJ73 / Jan.1990-Aug.1999

List price(Tax included)

265,000yen (291,500yen)

Lift

Front 60mm
Rear 80mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / 2 short, 2 long
Item Number

71730-13

Compatibility

HZJ73 / Jan.1990-Aug.1999

List price(Tax included)

275,000yen (302,500yen)

Lift

80mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / 4 long
Item Number

71730-51

Compatibility

HZJ73 / Jan.1990-Aug.1999

List price(Tax included)

271,000yen (298,100yen)

Lift

60mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / 4 short
Item Number

71730-51S

Compatibility

HZJ73 / Jan.1990-Aug.1999

List price(Tax included)

286,500yen (315,150yen)

Lift

60mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

Yes

notes

Alshackle / 4 short

LAND CRUISER 70(PZJ70)

Item Number

71707-11

Compatibility

PZJ70 / Jan.1990-Dec.1993

List price(Tax included)

253,000yen (278,300yen)

Lift

50mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / Short x 4 pcs.
Item Number

71707-12

Compatibility

PZJ70 / Jan.1990-Dec.1993

List price(Tax included)

263,000yen (289,300yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / Long x 2, Short x 2 pcs.
Item Number

71707-13

Compatibility

PZJ70 / Jan.1990-Dec.1993

List price(Tax included)

273,000yen (300,300yen)

Lift

Front 70mm
Rear 70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / Long x 4 pcs.
Item Number

71707-51

Compatibility

PZJ70 / Jan.1990-Dec.1993

List price(Tax included)

269,000yen (295,900yen)

Lift

50mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / Short x 4 pcs.
Item Number

71707-51S

Compatibility

PZJ70 / Jan.1990-Dec.1993

List price(Tax included)

284,500yen (312,950yen)

Lift

50mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

Yes

notes

Alshackle / Short x 4 pcs.

LAND CRUISER 70(HZJ70 hood roof)

Item Number

71707-51

Compatibility

HZJ70幌 / Jan.1994-Aug.1999

List price(Tax included)

269,000yen (295,900yen)

Lift

Front/60mmUP
Rear/30mmUP

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

---

notes

Alshackle / 4 short
Item Number

71707-51S

Compatibility

HZJ70幌 / Jan.1994-Aug.1999

List price(Tax included)

284,500yen (312,950yen)

Lift

Front/60mmUP
Rear/30mmUP

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

Steering damper

Yes

notes

Alshackle / 4 short

LAND CRUISER 70(HZJ77)

Item Number

71778-11

Compatibility

HZJ77/PZJ77 / Apr.1990-Aug.1999

List price(Tax included)

306,000yen (336,600yen)

Lift

70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

notes

Alshackle / Short x 4 pcs.
Item Number

71778-12

Compatibility

HZJ77/PZJ77 / Apr.1990-Aug.1999

List price(Tax included)

316,000yen (347,600yen)

Lift

Front 70mm
Rear 90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

notes

Alshackle / 2 short, 2 long
Item Number

71778-13

Compatibility

HZJ77/PZJ77 / Apr.1990-Aug.1999

List price(Tax included)

326,000yen (358,600yen)

Lift

90mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

notes

Alshackle / 4 long
Item Number

71778-51

Compatibility

HZJ77/PZJ77 / Apr.1990-Aug.1999

List price(Tax included)

322,000yen (354,200yen)

Lift

70mm

Products included

Spring(F)

Yes (leaf)

Spring(R)

Yes (leaf)

Absorber(F)

Yes (8-level damping adjustment)

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer stay

Yes

notes

Alshackle / 4 short

LAND CRUISER 70(HZJ76)

Item Number

71764-11A

Compatibility

HZJ76 / Sep.1999-

List price(Tax included)

247,000yen (271,700yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer block

Yes

Steering damper

---

notes
Item Number

71764-11SA

Compatibility

HZJ76 / Sep.1999-

List price(Tax included)

262,500yen (288,750yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer block

Yes

Steering damper

Yes

notes
Item Number

71764-51A

Compatibility

HZJ76 / Sep.1999-

List price(Tax included)

255,000yen (280,500yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer block

Yes

Steering damper

---

notes
Item Number

71764-51SA

Compatibility

HZJ76 / Sep.1999-

List price(Tax included)

270,500yen (297,550yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes (8-level damping adjustment)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer block

Yes

Steering damper

Yes

notes

LAND CRUISER 70(GRJ76)

Item Number

71763-15

Compatibility

GRJ76K / Sep.2013-

List price(Tax included)

307,000yen (337,700yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71763-15S

Compatibility

GRJ76K / Sep.2013-

List price(Tax included)

322,500yen (354,750yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71763-35

Compatibility

GRJ76K / Sep.2013-

List price(Tax included)

331,000yen (364,100yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71763-35S

Compatibility

GRJ76K / Sep.2013-

List price(Tax included)

346,500yen (381,150yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

LAND CRUISER 70(GRJ79)

Item Number

71794-11

Compatibility

GRJ79K / Sep.2013-

List price(Tax included)

367,200yen (403,920yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71794-11S

Compatibility

GRJ79K / Sep.2013-

List price(Tax included)

382,700yen (420,970yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71794-31

Compatibility

GRJ79K / Sep.2013-

List price(Tax included)

391,200yen (430,320yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes
Item Number

71794-31S

Compatibility

GRJ79K / Sep.2013-

List price(Tax included)

406,700yen (447,370yen)

Lift

Front 50mm
Rear 70mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

LAND CRUISER 70(GRJ79 for Heavy Load)

Item Number

71796-11

Compatibility

GRJ79K / Sep.2013- for Heavy Load

List price(Tax included)

383,200yen (421,520yen)

Lift

Front 65mm
Rear 130 to 140mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

*Manufacture to order
For heavy Load (Rear load is increased by 60 to 70mm compared to stock when rear load is increased by 200 to 300kg due to cargo bed installation, etc.)
Item Number

71796-11S

Compatibility

GRJ79K / Sep.2013- for Heavy Load

List price(Tax included)

398,700yen (438,570yen)

Lift

Front 65mm
Rear 130 to 140mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

*Manufacture to order
For heavy Load (Rear load is increased by 60 to 70mm compared to stock when rear load is increased by 200 to 300kg due to cargo bed installation, etc.)
Item Number

71796-31

Compatibility

GRJ79K / Sep.2013- for Heavy Load

List price(Tax included)

407,200yen (447,920yen)

Lift

Front 65mm
Rear 130 to 140mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

*Manufacture to order
For heavy Load (Rear load is increased by 60 to 70mm compared to stock when rear load is increased by 200 to 300kg due to cargo bed installation, etc.)
Item Number

71796-31S

Compatibility

GRJ79K / Sep.2013- for Heavy Load

List price(Tax included)

422,700yen (464,970yen)

Lift

Front 65mm
Rear 130 to 140mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (leaf)

Absorber(F)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes
(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

LSPV Bolt

Yes

Stabilizer stay set

Yes

notes

*Manufacture to order
For heavy Load (Rear load is increased by 60 to 70mm compared to stock when rear load is increased by 200 to 300kg due to cargo bed installation, etc.)

LAND CRUISER 70(GDJ76)

Item Number

NEW!
71768-15

Matching

GDJ76

Price(Tax included)

312,000yen (343,200yen)

Lift

Front 60mm
Rear 55mm

Products included

Spring(F)

Yes(Coil)

Spring(R)

Yes(Leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

Stabilizer stay set

Yes

notes

Depending on the size other than the factory size or the shape other than the factory rear bumper, it may be necessary to take measures to comply with safety standards (e.g., installation of an anti-rush device).
Item Number

NEW!
71768-15S

Matching

GDJ76

Price(Tax included)

327,500yen (360,250yen)

Lift

Front 60mm
Rear 55mm

Products included

Spring(F)

Yes(Coil)

Spring(R)

Yes(Leaf)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

Stabilizer stay set

Yes

notes

Depending on the size other than the factory size or the shape other than the factory rear bumper, it may be necessary to take measures to comply with safety standards (e.g., installation of an anti-rush device).
Item Number

NEW!
71768-35

Matching

GDJ76

Price(Tax included)

336,000yen (369,600yen)

Lift

Front 60mm
Rear 55mm

Products included

Spring(F)

Yes(Coil)

Spring(R)

Yes(Leaf)

Absorber(F)

Yes(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

---

Brake hose

Yes

Stabilizer stay set

Yes

notes

Depending on the size other than the factory size or the shape other than the factory rear bumper, it may be necessary to take measures to comply with safety standards (e.g., installation of an anti-rush device).
Item Number

NEW!
71768-35S

Matching

GDJ76

Price(Tax included)

351,500yen (386,650yen)

Lift

Front 60mm
Rear 55mm

Products included

Spring(F)

Yes(Coil)

Spring(R)

Yes(Leaf)

Absorber(F)

Yes(14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes(14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Bushings

Yes

Alshackle

Yes

Front stabilizer down block

Yes

Front lateral Rod

Yes

Steering damper

Yes

Brake hose

Yes

Stabilizer stay set

Yes

notes

Depending on the size other than the factory size or the shape other than the factory rear bumper, it may be necessary to take measures to comply with safety standards (e.g., installation of an anti-rush device).

LAND CRUISER 80

Item Number

NEW!
71807-31

Matching

LAND CRUISER 80
FJ80G , FZJ80G , HDJ81V , HZJ81V

Price(Tax included)

204,000yen (224,400yen)

Lift

Early model ／ 3.0inch
Mid-term & Late model ／ 4.5inch(110～120mm)

Products included

Spring(F)

Yes(Coil)

Spring(R)

Yes(Coil)

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

notes

Early model: Oct. 1989-
Mid-term model: Aug. 1992-
Late model: Jan.1995-
Gasoline/Diesel common
Item Number

71804-11

Compatibility

LAND CRUISER 80
FJ80G , FZJ80G , HDJ81V , HZJ81V

List price(Tax included)

158,000yen (173,800yen)

Lift

Early model / 0.5inch
Mid-term & Late model / 2inch(50mm)

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

notes

Early model: Oct. 1989-
Mid-term model: Aug. 1992-
Late model: Jan.1995-
Gasoline/Diesel common

LAND CRUISER 100

Item Number

71100-11R

Compatibility

HDJ101K/UZJ100W / Jan.1998-July 2007

List price(Tax included)

112,000yen (123,200yen)

Lift

Rear 50mm

Products included

Spring(F)

---

Spring(R)

Yes (Coil)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

notes

Not for AHC and Skyhook TEMS vehicles
*The front ride height is adjusted with a torsion bar.

HILUX 125

Item Number

71125-31

Compatibility

(GUN125)
September, 2017-.
Can be installed on all year models/GR

List price(Tax included)

159,400yen (175,340yen)

Lift

Front 20 to 60mm
Rear 0mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

---

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Absorber wrench

Yes

notes
Item Number

71125-31M

Compatibility

GUN125
September, 2017-.
Can be installed on all year models/GR

List price(Tax included)

173,400yen (190,740yen)

Lift

Front 20 to 60mm
Rear 0mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

---

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Absorber wrench

Yes

Upper mount

Yes(Front)

notes
Item Number

71125-31B

Compatibility

GUN125
September, 2017-.
Can be installed on all year models/GR

List price(Tax included)

194,400yen (213,840yen)

Lift

Front 20 to 60mm
Rear 35mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

---

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Absorber wrench

Yes

Block

Yes(Rear)

notes
Item Number

71125-31MB

Compatibility

GUN125
September, 2017-.
Can be installed on all year models/GR

List price(Tax included)

208,400yen (229,240yen)

Lift

Front 20 to 60mm
Rear 35mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

---

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Absorber wrench

Yes

Upper mount

Yes(Front)

Block

Yes(Rear)

notes

LAND CRUISER PRADO 150

Item Number

71151-31

Compatibility

TRJ150,GDJ150

List price(Tax included)

178,000yen (195,800yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

---

Rear lateral Rod

---

Upper mount

---

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.
Item Number

71151-31M

Compatibility

TRJ150,GDJ150

List price(Tax included)

193,000yen (212,300yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

---

Rear lateral Rod

---

Upper mount

Yes

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.
Item Number

71151-32

Compatibility

TRJ150,GDJ150

List price(Tax included)

182,800yen (201,080yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

---

Upper mount

---

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.
Item Number

71151-32M

Compatibility

TRJ150,GDJ150

List price(Tax included)

216,800yen (238,480yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

---

Upper mount

Yes

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.
Item Number

71151-33

Compatibility

TRJ150,GDJ150

List price(Tax included)

218,800yen (240,680yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

Yes

Upper mount

---

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.
Item Number

71151-33M

Compatibility

TRJ150,GDJ150

List price(Tax included)

233,800yen (257,180yen)

Lift

TRJ150
Front 25 to 80mm
Rear 40mm

Lift

GDJ150
Front 10 to 80mm
Rear 40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

Yes

Upper mount

Yes

Absorber wrench

Yes

notes

Not for installation on grade TZ-G rear air suspension vehicles.

LAND CRUISER PRADO 150 (Option Parts) Top Dial Attachment

Item Number

CS-036

Compatibility

Exclusive for TRJ150,GDJ150 Front Shock Absorber (for CEF042AJ)

List price(Tax included)

2,200yen(2,420yen)/one

notes

Attachment for damping force adjustment dial. Number required for 1 car: 2 pcs.

LAND CRUISER PRADO 90

Item Number

71952-11

Compatibility

KZJ/KDJ95 / May 1996-Sep.2002

List price(Tax included)

121,000yen (133,100yen)

Lift

50mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

notes

Optional Repair Parts: Driveshaft Boot (CS-022)

FJ CRUISER

Item Number

71151-55

Compatibility

GSJ15W / Nov.2010-

List price(Tax included)

178,000yen (195,800yen)

Lift

Front 35 to 55mm
Rear 40 to 50mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

---

Rear lateral Rod

---

Stabilizer

---

Absorber wrench

Yes

notes

*Not available for vehicles equipped with X-REAS.
Item Number

71151-56

Compatibility

GSJ15W / Nov.2010-

List price(Tax included)

218,800yen (240,680yen)

Lift

Front 35 to 55mm
Rear 40 to 50mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

Yes

Stabilizer

---

Absorber wrench

Yes

notes

*Not available for vehicles equipped with X-REAS.
Item Number

71151-57

Compatibility

GSJ15W / Nov.2010-

List price(Tax included)

277,800yen (305,580yen)

Lift

Front 35 to 55mm
Rear 40 to 50mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes (40-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber boots

Yes

Front stabilizer down block

Yes

Rear lateral Rod

Yes

Stabilizer

Yes

Absorber wrench

Yes

notes

*Not available for vehicles equipped with X-REAS.

HILUX SURF

Item Number

71952-11

Compatibility

KZN/KDN185 / Dec.1995-Oct.2002

List price(Tax included)

121,000yen (133,100yen)

Lift

40mm

Products included

Spring(F)

Yes (Coil)

Spring(R)

Yes (Coil)

Absorber(F)

Yes

Absorber(R)

Yes

Absorber boots

Yes

notes

Optional Repair Parts: Driveshaft Boot (CS-022)

*The amount of lift is the size measured by us.
*When replacing the leaf spring and shackle, structural modification is required.(in JAPAN)

Suspension Kit Itemized Statement (pdf)

JIMNY

JB64 30mm Lift up kit JB64 70mm Lift up kit
JB74 30mm Lift up kit JB74 70mm Lift up kit
JB23

JIMNY(JB64) 30mm Lift up

Item Number

74642-31

Compatibility

JB64

List price(Tax included)

122,000yen (134,200yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74642-31L

Compatibility

JB64

List price(Tax included)

124,600yen (137,060yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

---

notes

XC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74642-31S

Compatibility

JB64

List price(Tax included)

142,500yen (156,750yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74642-31LS

Compatibility

JB64

List price(Tax included)

145,100yen (159,610yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

XC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74642-32

Compatibility

JB64

List price(Tax included)

166,000
(182,600)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74642-32L

Compatibility

JB64

List price(Tax included)

168,600yen (185,460yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

---

notes

XC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74642-32S

Compatibility

JB64

List price(Tax included)

186,500yen (205,150yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74642-32LS

Compatibility

JB64

List price(Tax included)

189,100yen (208,010yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

XC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74642-33

Compatibility

JB64

List price(Tax included)

173,000yen (190,300yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74642-33L

Compatibility

JB64

List price(Tax included)

175,600yen (193,160yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

Yes

Steering damper

---

notes

XC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74642-33S

Compatibility

JB64

List price(Tax included)

193,500yen (212,850yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74642-33LS

Compatibility

JB64

List price(Tax included)

196,100yen (215,710yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

XC grade (with LED headlamps and auto-leveling mechanism) only

JIMNY(JB64) 70mm Lift up

*The Jimny JB64 may not comply with the safety standards without modification due to the 70mm lift. In accordance with the safety standards of each country, it is necessary to install a mirror or camera that complies with the front side driving visibility standards. Please take measures according to your respective needs.

Item Number

NEW!
74644-31

Compatibility

JB64

List price(Tax included)

195,300yen (214,830yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

---

LED Headlight levelizer stay

---

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

---
Item Number

NEW!
74644-31L

Compatibility

JB64

List price(Tax included)

199,100yen (219,010yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

---

LED Headlight levelizer stay

◯

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

XC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74644-31S

Compatibility

JB64

List price(Tax included)

215,800yen(237,380yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

◯

LED Headlight levelizer stay

---

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

---
Item Number

NEW!
74644-31LS

Compatibility

JB64

List price(Tax included)

219,600yen(241,560yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

◯

LED Headlight levelizer stay

◯

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

XC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74644-32

Compatibility

JB64

List price(Tax included)

263,800yen (290,180yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

---

LED Headlight levelizer stay

---

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

---
Item Number

NEW!
74644-32L

Compatibility

JB64

List price(Tax included)

267,600yen (294,360yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

---

LED Headlight levelizer stay

◯

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

XC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74644-32S

Compatibility

JB64

List price(Tax included)

284,300yen (312,730yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

◯

LED Headlight levelizer stay

---

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

---
Item Number

NEW!
74644-32LS

Compatibility

JB64

List price(Tax included)

288,100yen (316,910yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

◯

LED Headlight levelizer stay

◯

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

XC grade (LED headlamps with auto-leveling mechanism) only

JIMNY(JB74) 30mm Lift up

Item Number

74743-31

Compatibility

JB74

List price(Tax included)

123,000yen (135,300yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74743-31L

Compatibility

JB74

List price(Tax included)

125,600yen (138,160yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

---

notes

JC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74743-31S

Compatibility

JB74

List price(Tax included)

143,500yen (157,850yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74743-31LS

Compatibility

JB74

List price(Tax included)

146,100yen (160,710yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

JC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74743-32

Compatibility

JB74

List price(Tax included)

167,000yen (183,700yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74743-32L

Compatibility

JB74

List price(Tax included)

169,600yen (186,560yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

---

notes

JC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74743-32S

Compatibility

JB74

List price(Tax included)

187,500yen (206,250yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74743-32LS

Compatibility

JB74

List price(Tax included)

190,100yen (209,110yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

JC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74743-33

Compatibility

JB74

List price(Tax included)

174,000yen (191,400yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

---

Steering damper

---

notes
Item Number

74743-33L

Compatibility

JB74

List price(Tax included)

176,600yen (194,260yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

Yes

Steering damper

---

notes

JC grade (with LED headlamps and auto-leveling mechanism) only
Item Number

74743-33S

Compatibility

JB74

List price(Tax included)

194,500yen (213,950yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

---

Steering damper

Yes

notes
Item Number

74743-33LS

Compatibility

JB74

List price(Tax included)

197,100yen (216,810yen)

Lift

30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment with built-in HARMO-FLEX)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

LED Headlight levelizer stay

Yes

Steering damper

Yes

notes

JC grade (with LED headlamps and auto-leveling mechanism) only

JIMNY(JB74) 70mm Lift up

*The Jimny JB74 may not comply with the safety standards without modification due to the 70mm lift. In accordance with the safety standards of each country, it is necessary to install a mirror or camera that complies with the front side driving visibility standards. Please take measures according to your respective needs.。

Item Number

NEW!
74745-31

Compatibility

JB74

List price(Tax included)

197,300yen (217,030yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

---

LED Headlight levelizer stay

---

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

---
Item Number

NEW!
74745-31L

Compatibility

JB74

List price(Tax included)

201,100yen (221,210yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

---

LED Headlight levelizer stay

◯

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

JC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74745-31S

Compatibility

JB74

List price(Tax included)

217,800yen (239,580yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

◯

LED Headlight levelizer stay

---

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

---
Item Number

NEW!
74745-31LS

Compatibility

JB74

List price(Tax included)

221,600yen (243,760yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

---

Rear lateral Rod

---

Steering damper

◯

LED Headlight levelizer stay

◯

Stabilizer downblock

---

Propeller shaft spacer

◯

Leading arm bushing

---

notes

JC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74745-32

Compatibility

JB74

List price(Tax included)

265,800yen (292,380yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

---

LED Headlight levelizer stay

---

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

---
Item Number

NEW!
74745-32L

Compatibility

JB74

List price(Tax included)

269,600yen (296,560yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

---

LED Headlight levelizer stay

◯

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

JC grade (LED headlamps with auto-leveling mechanism) only
Item Number

NEW!
74745-32S

Compatibility

JB74

List price(Tax included)

286,300yen (314,930yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

◯

LED Headlight levelizer stay

---

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

---
Item Number

NEW!
74745-32LS

Compatibility

JB74

List price(Tax included)

290,100yen (319,110yen)

Lift

70mm

Products included

Spring(F)

◯

Spring(R)

◯

Absorber(F)

◯(14-level damping adjustment with built-in Harmoflex)

Absorber(R)

◯(14-level damping adjustment with built-in Harmoflex)

Rear shock spacer

◯

Cross-member down bracket

◯

Brake hose

◯

Air hose + ABS wiring stay

◯

Front lateral Rod

◯

Rear lateral Rod

◯

Steering damper

◯

LED Headlight levelizer stay

◯

Stabilizer downblock

◯

Propeller shaft spacer

◯

Leading arm bushing

◯

notes

JC grade (LED headlamps with auto-leveling mechanism) only

JIMNY(JB23)

Item Number

74231-11

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

114,200yen (125,620yen)

Lift

65mm
*Long brake hoses are required separately.

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---
Item Number

74230-11

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

84,000yen (92,400yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes

Absorber(R)

Yes

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---
Item Number

74230-12

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

123,500yen (135,850yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes

Absorber(R)

Yes

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---
Item Number

74230-13

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

130,500yen (143,550yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes

Absorber(R)

Yes

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes
Item Number

74230-35

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

108,000yen (118,800yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---
Item Number

74230-36

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

147,500yen (162,250yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

---
Item Number

74230-37

Compatibility

JB23 / Oct.1998-Jul.2018

List price(Tax included)

154,500yen (169,950yen)

Lift

50mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (14-level damping adjustment)

Absorber(R)

Yes (14-level damping adjustment)

Front lateral Rod

Yes

Rear lateral Rod

Yes

Leading arm bushing

Yes

*The amount of lift is the size measured by us.

Suspension Kit Itemized Statement (pdf)

DELICA

D:5

DELICA D:5(CV1W after minor changes in February 2019)

Item Number

73059-31

Compatibility

CV1W / Feb.2019-

List price(Tax included)

183,000yen (201,300yen)

Lift

Front 20 to 25mm
Rear 25 to 30mm

Products included

Spring(F)

Yes

Spring(R)

Yes

Absorber(F)

Yes (HLS valves)

Absorber(R)

Yes (8-level damping adjustment)

Stabilizer link

Yes

Front lateral Rod

---

Rear lateral Rod

---

Leading arm bushing

---

LED Headlight levelizer stay

---

Steering damper

---

notes

Exclusively designed for 4WD diesel vehicles after minor change

*The amount of lift is the size measured by us.

Sensitive evaluation of driving by test drivers

What is the HLS valve, a high damping valve at low speed?

In the Country Suspension Kit for Delica D:5, the front side shock absorber is equipped with the "HLS valve" mechanism developed by KYB.
The first feature of the HLS valve is that the damping force can be set higher when the amplitude of the shock absorber is slower, for example when the steering wheel is turned. This reduces body roll and pitching, further improving handling stability.
In addition, the damping force is maintained at a low level in order to absorb the high amplitude, "thrusting" input that occurs when passing over bridges and highway junctions.
By successfully controlling the two conflicting characteristics, we have achieved a further improvement in handling stability.

Reference: "MORE" Technology 3 Keyword of KYB
