SHOCK ABSORBER

4WD only. Shock absorbers adjusted to suit the characteristics of each model.

Scroll

A standard lineup that pursues the performance required of a 4WD

SHOCK ABSORBER

This shock absorber is designed for shock absorption performance and ride comfort, and has been adjusted to meet the characteristics of each 4WD model.

Please try out the Big Country's standard lineup, including models with damping adjustment.

Use the damping force adjustment mechanism.

From on-road to rugged off-road, there are a wide variety of environments in which 4WDs can operate.
By adjusting the damping force of the shock absorber to the optimum value according to the driving environment, the true potential of the vehicle can be brought out even more.
Basic knowledge about damping force adjustment and tips for adjusting to the optimum value are summarized in "Recommendations for Damping Force Adjustment". Please take a look.

Shock absorber for JB64

New shock absorber mechanism for both ride comfort and handling stability

HARMO-FLEX

Frequency-sensitive shock absorber "HARMO-FLEX" is adopted (*on some models)

"HARMO-FLEX" is a frequency-sensitive shock absorber, a new shock absorber mechanism developed by KYB Corporation to achieve both ride comfort and driving stability, and mass production of which began in 2009.

With conventional shock absorbers, the damping force is almost constant even if the vibration frequency changes as long as the speed remains the same.

On the other hand, "HARMO-FLEX" reduces the vibration of the vehicle body by setting the damping force lower than that of conventional shock absorbers for vibration frequencies of 3Hz or higher, which is the frequency at which humans perceive ride comfort to be good or bad.

Conversely, the damping force is set higher than that of conventional shock absorbers when the resonance frequency on the spring is below about 1.5Hz. This prevents deterioration of handling stability due to insufficient rise of damping force.

In this way, by automatically changing the damping force according to the vibration frequency of the road surface and vehicle body, the vehicle's handling stability can be enhanced while ride comfort can be greatly improved.

*Depending on the model of car, changing the ride height by installing our ride height adjustment parts may also require changing the settings of the cameras, sensors, and radars installed in the car. If not properly adjusted, the various safety equipment (such as collision avoidance and other driving support systems) in the car may not operate properly. Also, please note that there is a possibility that the vehicle will not meet the front side visibility standard (Article 44, Paragraph 5 of the safety standard).

*We are not responsible for any accidents caused by the malfunction of the camera, sensor, radar, or driver assistance system due to the installation of our parts. Please understand beforehand.

SHOCK ABSORBER LINE-UP

TOYOTA

LAND CRUISER 60 and 70

  • CWF007
    Item Number
    CWF007
    Compatibility
    LAND CRUISER 70 / J7#series / Nov.1984-Jul.1999
    LAND CRUISER 60 / J6#series / Sept.1987-Sept.1989
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    632
    Minimum Length(mm)
    380
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / 0 to +30mm
    Land Cruiser 60 J6#series / +50 to +80mm
  • CWF008
    Item Number
    CWF008
    Compatibility
    LAND CRUISER 70 / J7#series / Nov.1984-Jul.1999
    LAND CRUISER 60 / J6#series / Sept.1987-Sept.1989
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    663
    Minimum Length(mm)
    397
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / +50 to +80mm
    Land Cruiser 60 J6#series / +80 to +100mm
  • CWR012
    Item Number
    CWR012
    Compatibility
    LAND CRUISER 70 / J7#series / Nov. 1984-July 1999
    HZJ70series / Aug.1999-
    LAND CRUISER 60 / J6#series / Sept.1987-Sept.1989
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    657
    Minimum Length(mm)
    404
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650 incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / +50 to +90mm
    Land Cruiser 70 HZJ70series / 0 to +70mm
    Land Cruiser 60 J6#series / +70 to +90mm
  • CEF040
    Item Number
    CEF040
    Compatibility
    LAND CRUISER 70 / J7#series / Nov.1984-Jul.1999
    LAND CRUISER 60 / J6#series / Sept.1987-Sept.1989
    for Front
    Machanism
    Low-pressure twin-tube
    8-level damping force adjustment
    List price(Tax included)
    20,500yen/one (22,550yen/one)
    Maximum Length(mm)
    655
    Minimum Length(mm)
    390
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / +50 to +70mm
    Land Cruiser 60 J6#series / +50 to +75mm
  • CER041
    Item Number
    CER041
    Compatibility
    LAND CRUISER 70 / J7#series / Nov.1984-Jul.1999
    LAND CRUISER 60 / J6#series / Sept.1987-Sept.1989
    for Rear
    Machanism
    Low-pressure twin-tube
    8-level damping force adjustment
    List price(Tax included)
    20,500yen/one (22,550yen/one)
    Maximum Length(mm)
    647
    Minimum Length(mm)
    395
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / +50 to +70mm
    Land Cruiser 60 J6#series / +50 to +75mm

LAND CRUISER 70

  • CWR011
    Item Number
    CWR011
    Compatibility
    LAND CRUISER 70 / J7#series / Nov.1984-Jul.1999
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    627
    Minimum Length(mm)
    387
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / 0 to +30mm
  • CWF048
    Item Number
    CWF048
    Compatibility
    HZJ7#series / (for Front Coil Vehicles)(Aug.1999-)
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    539
    Minimum Length(mm)
    327
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Corresponding lift capacity:
    Land Cruiser 70 J7#series / 0 to +70mm
  • CEF045H
    Item Number
    CEF045H
    Compatibility
    GRJ7#series / Aug.2013-
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    22,500yen/one (24,750yen/one)
    Maximum Length(mm)
    545
    Minimum Length(mm)
    342
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Cannot be installed at stock ride height
    Corresponding lift capacity:
    Land Cruiser 70 GRJ7#series / +40 to +60mm
  • CER046H
    Item Number
    CER046H
    Compatibility
    GRJ7#series / Aug.2013-
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    22,500yen/one (24,750yen/one)
    Maximum Length(mm)
    690
    Minimum Length(mm)
    429
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Cannot be installed at stock ride height
    Corresponding lift capacity:
    Land Cruiser 70 GRJ7#series / +40 to +60mm
  • CEF047H
    Item Number
    CEF047H
    Compatibility
    GRJ7#series / Aug.2013-
    for Front
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    22,500yen/one (24,750yen/one)
    Maximum Length(mm)
    490
    Minimum Length(mm)
    330
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    For stock ride height
    Corresponding lift capacity:
    Land Cruiser 70 GRJ7#series / 0 to +20mm
  • CER048H
    Item Number
    CER048H
    Compatibility
    GRJ7#series / Aug.2013-
    for Rear
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    22,500yen/one (24,750yen/one)
    Maximum Length(mm)
    655
    Minimum Length(mm)
    412
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650 incl. tax)
    For stock ride height
    Corresponding lift capacity:
    Land Cruiser 70 GRJ7#series / 0 to +20mm
  • S1076-4748-65
    Item Number
    S1076-4748-65
    Compatibility
    GDJ76 / Dec.2023-
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    107,000yen/Kit for 1 car
    (117,700yen/Kit for 1 car)
    Maximum Length(mm)
    Front 490
    Rear 655
    Minimum Length(mm)
    Front 330
    Rear 412
    Attached Parts
    Rear bump stopper extension stopper
    Big Country Equip Shock boots (Part No. SAB17BL)
    notes
    0 to +20mm
    Rear bump stopper extension spacer (single item)
      Item No.: CS-065
      List price: 11,000yen(12,100yen)
      Thickness of spacer: 20mm
  • S1076-4748-65
    Item Number
    S1076-4748-6566
    Compatibility
    GDJ76 / Dec.2023-
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    Built-in HARMO-FLEX function
    List price(Tax included)
    122,800yen/Kit for 1 car
    (¥135,080yen/Kit for 1 car)
    Maximum Length(mm)
    Front 490
    Rear 655
    Minimum Length(mm)
    Front 330
    Rear 412
    Attached Parts
    Front coil spacer
    Rear bump stopper extension stopper
    Big Country Equip Shock boots (Part No. SAB17BL)
    notes
    0 to +20mm
    Rear bump stopper extension spacer (single item)
      Item No.: CS-065
      List price: 11,000yen(12,100yen)
      Thickness of spacer: 20mm
    Front coil spacer (single item)
      Item No.: CS066
      List price: 15,800yen(17,380yen)
      Lift: 15mm

LAND CRUISER 80

  • S1080-2324
    Item Number
    S1080-2324
    Compatibility
    LAND CRUISER 80
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    72,000yen (79,200yen)/Set of 4
    Maximum Length(mm)
    Front/640
    Rear/615
    Minimum Length(mm)
    Front/372
    Rear/368
    notes
    Big Country Shock Boots (part number SAB17BL) included
  • S1080-2324
    Item Number
    CWF023
    Compatibility
    LAND CRUISER 80
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    640
    Minimum Length(mm)
    372
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
  • S1080-2324
    Item Number
    CWR024
    Compatibility
    LAND CRUISER 80
    for Rear
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen (18,150yen)
    Maximum Length(mm)
    615
    Minimum Length(mm)
    368
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)

LAND CRUISER 100

  • CWF043forFro
    Item Number
    CWF043(for Front)
    Compatibility
    HDJ101K/UZJ100W Jan.1998-Jul.2007
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    17,500yen/one (19,250yen/one)
    Maximum Length(mm)
    452
    Minimum Length(mm)
    292
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650 incl. tax)
    Not for AHC&Skyhook TEMS vehicles
    Compatible lifts: Land Cruiser 100 / 0 to +75mm
  • CWR044forRea
    Item Number
    CWR044(for Rear)
    Compatibility
    HDJ101K/UZJ100W / Jan.1998-Jul.2007
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    17,500yen/one (19,250yen/one)
    Maximum Length(mm)
    623
    Minimum Length(mm)
    379
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650 incl. tax)
    Not for AHC&Skyhook TEMS vehicles
    Compatible lifts: Land Cruiser 100 / 0 to +75mm

LAND CRUISER PRADO

  • CWF039
    Item Number
    CWF039
    Compatibility
    LAND CRUISER PRADO / J9#series / May 1996-Sept.2002
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    470
    Minimum Length(mm)
    326
    notes
    Big Country Shock Boots (part number SAB17BL) included
    Compatible lift: Prado J9#series/+20 to +50mm
  • CWR040
    Item Number
    CWR040
    Compatibility
    LAND CRUISER PRADO / J9#series / May 1996-Sept.2002
    for Rear
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    530
    Minimum Length(mm)
    338
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Compatible lift: Prado J9#series/+20 to +50mm

HILUX SURF

  • CWF039
    Item Number
    CWF039
    Compatibility
    HILUX SURF / N185series / Dec.1995-Oct.2002
    for Front
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    470
    Minimum Length(mm)
    326
    notes
    Big Country Shock Boots (part number SAB17BL) included
    Compatible lift: HILUX SURF N185series/+20 to +50mm
  • CWR040
    Item Number
    CWR040
    Compatibility
    HILUX SURF / N185series / Dec.1995-Oct.2002
    for Rear
    Machanism
    Low-pressure twin-tube
    List price(Tax included)
    16,500yen/one (18,150yen/one)
    Maximum Length(mm)
    530
    Minimum Length(mm)
    338
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)

FJ CRUISER

  • CEF042-AJ
    Item Number
    CEF042-AJ
    Compatibility
    FJ CRUISER / GSJ15W / Nov.2010-
    for Front
    Machanism
    40-level damping force adjustment
    Ride height adjustable
    Low-pressure twin-tube
    List price(Tax included)
    38,000yen/one (41,800yen/one)
    Maximum Length(mm)
    572
    Minimum Length(mm)
    450
    notes
    Big Country Shock Boots (part number SAB17BL) included
  • CER044
    Item Number
    CER044
    Compatibility
    FJ CRUISER / GSJ15W / Nov.2010-
    for Rear
    Machanism
    14-level damping force adjustment
    Low-pressure twin-tube
    Built-in HARMO-FLEX function
    List price(Tax included)
    22,000yen/one (24,200yen/one)
    Maximum Length(mm)
    590
    Minimum Length(mm)
    355
    notes
    Big Country Shock Boots (Part No. SAB17BL) sold separately (1,650yen incl. tax)
    Compatible lifts: FJ GSJ15W/+20 to +50mm

BIG COUNTRY Shock Boots

  • SAB09BL
    Item Number
    SAB09BL
    Compatibility
    general purpose
    List price(Tax included)
    1,500yen/one (1,650yen/one)
    notes
    *The picture shows 2 pieces.
  • SAB17BL
    Item Number
    SAB17BL
    Compatibility
    general purpose
    List price(Tax included)
    1,500yen/one (1,650yen/one)
    notes
    *The picture shows 2 pieces.

SUZUKI

JIMNY(JB64 / JB74)

  • S4674-4950
    Item Number
    S4674-4950
    Compatibility
    JIMNY JB64/74 series
    for Front & Rear
    Machanism
    14-level damping force adjustment
    Built-in HARMO-FLEX function (front)
    List price(Tax included)
    80,000yen (88,000yen) / Set of 4
    Maximum Length(mm)
    440
    Minimum Length(mm)
    294
    notes
    0 to about 30 mm up
  • CEF049H
    Item Number
    CEF049H
    Compatibility
    JIMNY JB64/74 series
    for Front
    Machanism
    14-level damping force adjustment
    Built-in HARMO-FLEX function (front)
    List price(Tax included)
    22,000yen/one (24,200yen/one)
    Maximum Length(mm)
    440
    Minimum Length(mm)
    294
    notes
    0 to about 30 mm up
  • CER050
    Item Number
    CER050
    Compatibility
    JIMNY JB64/74 series
    for Rear
    Machanism
    14-level damping force adjustment
    List price(Tax included)
    18,000yen/one (19,800yen/one)
    Maximum Length(mm)
    475
    Minimum Length(mm)
    307
    notes
    0 to about 30 mm up
  • s4674-5556
    Item Number

    NEW!
    S4674-5556

    Compatibility
    JIMNY JB64/74 series
    for Front & Rear
    Machanism
    14-level damping force adjustment
    Built-in Harmo-flex function
    List price(Tax included)
    87,000yen/Set of 4 (98,700yen/Set of 4)
    Maximum Length(mm)
    Front 495
    Rear 540
    Minimum Length(mm)
    Front 322
    Rear 340
    notes
    For 70mm up, Rear shock spacer (Part No. CS-052) included
  • cef055h
    Item Number

    NEW!
    CEF055H

    Compatibility
    JIMNY JB64/74 series
    for Front
    Machanism
    14-level damping force adjustment
    Built-in Harmo-flex function
    List price(Tax included)
    23,000yen/one (25,300yen/one)
    Maximum Length(mm)
    495
    Minimum Length(mm)
    322
    notes
    For 70mm up
  • cer056h
    Item Number

    NEW!
    CER056H

    Compatibility
    JIMNY JB64/74 series
    for Rear
    Machanism
    14-level damping force adjustment
    Built-in Harmo-flex function
    List price(Tax included)
    20,000yen/one (22,000/one)
    Maximum Length(mm)
    540
    Minimum Length(mm)
    340
    notes
    For 70mm up

JIMNY(JB23)

  • CWJF005
    Item Number
    CWJF005
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Front
    Machanism
    List price(Tax included)
    12,000yen/one (13,200yen/one)
    Maximum Length(mm)
    460
    Minimum Length(mm)
    282
    notes
    0-2 inches up
  • CWJR006
    Item Number
    CWJR006
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Rear
    Machanism
    List price(Tax included)
    12,000yen/one (13,200yen/one)
    Maximum Length(mm)
    504
    Minimum Length(mm)
    311
    notes
    0-2 inches up
  • CEF028-14
    Item Number
    CEF028-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Front
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,000yen/one (19,800yen/one)
    Maximum Length(mm)
    460
    Minimum Length(mm)
    307
    notes
    Big Country Equip.
    2 inches up
  • CER029-14
    Item Number
    CER029-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Rear
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,000yen/one (19,800yen/one)
    Maximum Length(mm)
    504
    Minimum Length(mm)
    331
    notes
    Big Country Equip.
    2 inches up
  • CEF030-14
    Item Number
    CEF030-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Front
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,000yen/one (19,800yen/one)
    Maximum Length(mm)
    415
    Minimum Length(mm)
    280
    notes
    Big Country Equip.
    Compatible with normal vehicle height
  • CER031-14
    Item Number
    CER031-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Rear
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,000yen/one (19,800yen/one)
    Maximum Length(mm)
    460
    Minimum Length(mm)
    309
    notes
    Big Country Equip.
    Compatible with normal vehicle height
  • S4023-3031
    Item Number
    S4023-3031
    Compatibility
    JIMNY JB23series / Oct.1998-
    Front and Rear
    Machanism
    低圧複筒式
    減衰力14段調整式
    List price(Tax included)
    72,000yen/car (79,200yen/car)
    Maximum Length(mm)
    Front 415
    Rear 460
    Minimum Length(mm)
    Front 280
    Rear 309
    notes
    Big Country Equip.
    Compatible with normal vehicle height
  • CEF035-14
    Item Number
    CEF035-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Front
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,800yen/one (20,680yen/one)
    Maximum Length(mm)
    495
    Minimum Length(mm)
    320
    notes
    Big Country Equip.
    3 inches up
  • CER036-14
    Item Number
    CER036-14
    Compatibility
    JIMNY JB23series / Oct.1998-
    for Rear
    Machanism
    Low-pressure twin-tube
    14-level damping force adjustment
    List price(Tax included)
    18,800yen/one (20,680yen/one)
    Maximum Length(mm)
    540
    Minimum Length(mm)
    349
    notes
    Big Country Equip.
    3 inches up

JIMNY(Others)

  • CWJF001
    Item Number
    CWJF001
    Compatibility
    JIMNY JA11,JA71,SJ30,SJ40 series / Apr.1980-Oct.1995
    for Front
    Machanism
    List price(Tax included)
    12,000yen/one (13,200yen/one)
    Maximum Length(mm)
    472
    Minimum Length(mm)
    290
    notes
    0-2 inches up
  • CWJR002
    Item Number
    CWJR002
    Compatibility
    JIMNY JA11,JA71,SJ30,SJ40 series / Apr.1980-Oct.1995
    for Rear
    Machanism
    List price(Tax included)
    12,000yen/one (13,200yen/one)
    Maximum Length(mm)
    471
    Minimum Length(mm)
    296
    notes
    0-2 inches up
  • S4022-0304
    Item Number
    S4022-0304
    Compatibility
    JIMNY JA12,JA22 / Nov.1995-Sept.1998
    Machanism
    List price(Tax included)
    54,000yen/car (59,400yen/car)
    Maximum Length(mm)
    Front 432
    Rear 390
    Minimum Length(mm)
    Front 273
    Rear 257
    notes
    0-1 inches up
    Set for front and rear

MITSUBISHI

DELICA D:5(CV1W after minor changes in February 2019)

  • S3051-5138
    Item Number
    S3051-5138
    Compatibility
    CV1W / Feb.2019-
    Machanism
    Low speed range high damping valves「HLS valves」(Front)
    8-level damping force adjustment (rear)
    List price(Tax included)
    125,000yen/4-piece set (137,500yen/4-piece set)
    Maximum Length(mm)
    Front:546.5
    Rear:485
    Minimum Length(mm)
    Front:404.3
    Rear:320
    notes
    Supported lifts: 0 to +30mm
